FIller Metal Breakdown
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
| Wire | Approvals |
|---|---|
| A-3 | ABS, BV, DNV, KR, LR, NK |
| Packaging |
|---|
| Tin Can 20kg (44lbs) |
| PE Bag 20kg (44lbs) |
| Packaging |
|---|
| Tin Can 20kg (44lbs) |
| PE Bag 20kg (44lbs) |
| Wire | C | Si | Mn | P | S | Mo | Ti | B |
|---|---|---|---|---|---|---|---|---|
| A-3/IRN-1/CBM-G22 | 0.06 | 0.28 | 1.40 | 0.017 | 0.002 | 0.25 | 0.02 | 0.004 |
| Wire | Condition | YS MPa(ksi) | TS MPa(ksi) | EL (%) | Temp °C (°F) | Impact ISO-V J (ft·lbs) |
|---|---|---|---|---|---|---|
| A-3/IRN-1/CBM-G22 | AC, Th.16mm(0.62in) | 520(75) | 620(90) | 24 | -60(75) | 75(55) |
