FIller Metal Breakdown
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
| ABS | BV | DNV | LR | CWB | CE |
|---|---|---|---|---|---|
| ✓ | ✓ | ✓ | ✓ | ✓ | ✓ |
| Diameter | Length | F&HF | V-up/OH | Packaging |
|---|---|---|---|---|
| 2.6(3/32) | 350(14) | 60-90 | 50-80 | Packet 5kg / Carton 20kg |
| 3.2(1/8) | 350/400 | 90-140 | 80-120 | Packet 5kg / Carton 20kg |
| 4.0(5/32) | 400/450 | 130-190 | 120-170 | Packet 5kg / Carton 20kg |
| 5.0(3/16) | 400/450 | 180-240 | 150-200 | Packet 5kg / Carton 20kg |
| Diameter | Length | F&HF | V-up/OH | Packaging |
|---|---|---|---|---|
| 2.6(3/32) | 350(14) | 60-90 | 50-80 | Packet 5kg / Carton 20kg |
| 3.2(1/8) | 350/400 | 90-140 | 80-120 | Packet 5kg / Carton 20kg |
| 4.0(5/32) | 400/450 | 130-190 | 120-170 | Packet 5kg / Carton 20kg |
| 5.0(3/16) | 400/450 | 180-240 | 150-200 | Packet 5kg / Carton 20kg |
| C | Si | Mn | P | S | Ni |
|---|---|---|---|---|---|
| 0.09 | 0.25 | 1.27 | 0.017 | 0.005 | 0.02 |
| Condition | Yield MPa(ksi) | Tensile MPa(ksi) | Elongation % | Temp °C (°F) | Impact J(ft·lbs) |
|---|---|---|---|---|---|
| As-weld | 461(67) | 570(83) | 31 | -45(-50) | 100(74) |
| 620℃*7hr | 451(65) | 551(80) | 31 | -45(-50) | 82(61) |
