SHARK 46

Plasma Welding

SHARK 46

PLASMA CUTTING 40A
Powerful and light SHARK 46 single phase plasma cutting equipment with PFC is the ideal choice for maintenance.
Powerful and light SHARK 46 single phase plasma cutting equipment with PFC is the ideal choice for car body repairs, agriculture and maintenance. PFC device ensures big cutting power coupled with a contained consumption.
Contact Us
Plasma Cutting

Other Characteristics

  • SV version with 115-230V 1-phase
  • SK75 torch with HPC High Performance Cutting technology and coaxial cable
  • PFC Power Factor Correction – 16A fuse
  • High power professional air flow circulation
  • Electronic control for an excellent cutting quality
  • Long life of consumable parts
  • Possibility of cutting grids and perforated lamination sheets
  • Contact cutting possibility
  • Torch with pilot arc
  • Cutting parameter stability within ±15% mains voltage fluctuations
  • Regulator group with built-in filter and air impurity automatic expulsion
  • Electric protection on the torch for the maximum safety of the operator

SHARK 46: Technical Features

TECHNICAL DATA SHARK 46 SHARK 46 SV
Input Voltage 50/60 Hz V 230-1ph 115/230-1ph
Input Power @ I2 max kVA 5 5
Delayed Fuse A 16 16
Current range A 20÷40 20÷30/40
Duty Cycle (40°C) 60% A 30 30
35% A 40 40
Cutting Capacity Recommended mm 12 10
Maximum mm 15 12
Severance mm 20 18
Piercing mm 10 –
Gas supply Air/N2
Gas Pressure bar 5,0-5,5
Gas Flow l/min 160÷180
Protection Class IP 23S
Dimensions (LxWxH) mm 390x185x595
Weight kg 16
